Specification of our 12v 100ah battery |
|
|
Nominal Voltage |
12.8V |
|
Nominal Capacity |
100Ah |
|
Rated Energy |
1280Wh |
|
Dimension |
329*172*230mm |
|
Cycle Life |
Over 4000 times @1C 80% DOD |
|
Max Continuous Current |
100A |
|
Discharge Cut-off Voltage |
10.0V |
|
Charge Mode |
CC/CV |
|
Charge Voltage |
14.6V |
|
Standard Charge Current |
20A |
|
Discharge Temperature |
-20℃ to 60 ℃ |
|
Charge Temperature |
0℃ to 45℃ |
|
Case Material |
ABS |
|
Weight |
About 11kgs |
|
Warranty time |
3 years |
|
Customized LOGO |
Acceptable |
|
Cell type |
Cylinder LiFePO4 |
Main feature of Tenry 12v 100ah lifepo4 battery:
* 3 years warranty according to the application.
* Standard ABS box for lead acid battery.
* Over 4000 Cycles at 80% DOD.
* Series and/or Parallel Operation.
* Automatic Cell balancing system.
* Temperature monitoring.
* Exceptional voltage stability.
* Maintenance free.
* Great for marine, RV, floor sweepers, lift gates, UPS systems, solar energy storage.
* Cell balancing and low voltage/over voltage protection, short-circuit protection.
* Maximize your energy potential with 100% Depth of Discharge (DOD).
* Comes with an 3 year limited warranty to give you peace of mind with your purchase.
* Drop in replacement design, it’s easy to change your lead acid battery to LiFePO4.
Main Application:
The lead-acid replacement lithium battery usually can be used on solar street light, RVs, golf carts, yachts, boats, solar energy storage system for residential, robot, etc.
Battery Handling Cautions:
1. Do not dispose the battery in fire or expose to the heat.
2. Do not reverse connection the battery.
3. Do not short circuit the battery.
4. Do not disassemble the battery.
5. Do not mix the battery with other type.
6. Do not put battery in water or get it wet.
7. Do not use unqualified charger to charge the battery.
8. Please use the battery under the right temperature range and right discharge current range.
